Fall Time: 3.5 ns,5.7 ns
Rise Time: 2.2 ns, 5.5 ns
Technology: Si
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 8 nC, 18 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 2.4 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 8.2 ns, 12 ns
Typical Turn-Off Delay Time: 16.5 ns, 23.2 ns
Id - Continuous Drain Current: 18.8 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 44 S
Rds On - Drain-Source Resistance: 4.38 mOhms
Vds - Drain-Source Breakdown Voltage: 30 V
Vgs th - Gate-Source Threshold Voltage: 1.2 V
