Channel: 1
Frequency Output: 60MHz
Sample Rate: 300MSa/s
Vertical Resolution: 14 bits
Waveform:
Standard Waveform: sine, square, pulse, ramp, noise
Arbitrary Waveform: exponential rise, exponential fall, sin(x)/x, step wave, and others,total 160 built-in waveforms
Frequency (resolution 1μHz):
Sine: 1μHz-60MHz
Square: 1μHz ~ 20MHz
Pulse: 1μHz ~ 20MHz
Ramp: 1μHz ~ 2MHz
Noise: 20MHz (-3dB，typical)
Arbitrary Waveform: 1μHz ~10MHz
Arbitrary:
Waveform Length: 2 points – 100K points
Sample Rate: 300MSa/s
Amplitude:
into 50Ω load: 1mVpp ~ 10Vpp（≤10Hz）; 1mVpp ~ 5Vpp （≤60MHz）
DC Offset Range （AD+DC）: ±(10 Vpk – Amplitude Vpp/2) high resistance; ±(5 Vpk – Amplitude Vpp/2) 50 Ω
DC offset resolution: 1mV or 4digits
Load Impedance: 50Ω (typical)
DC offset Accuracy: ±(1 % of |setting| + 1 mV + amplitude Vpp * 0.5%)
Modulation:
Type: AM、FM、PM、PWM、FSK、3FSK、4FSK、PSK、ASK、BPSK、OSK、DSB-AM、QPSK、SUM、Sweep、Burst
Frequency Counter:
Function: Frequency， period
Frequency Range: 100mHz ~ 200MHz
Frequency Resolution: 6 digits
Input / Output:
Display: 3.6” LCD
Input mode: external modulation input, external trigger input, external reference clock input / output
Communication Interface: USB Host, USB Device
Mechanical specifications:
Dimension (W×H×D): 200 x 92 x 157mm
Weight (without package): 0.8kg
