Bandwidth: 120MHz
Sample Rate: 1GS/s
Vertical Resolution (A/D): 8bits
Record length: 40m
Waveform Refresh Rate: 45000 wfms/s
Horizontal Scale (s/div): 1ns/div - 1000s/div, step by 1 - 2 - 5
Channel: 2
Display: 4 1/2 digitals:
Voltage:
mV: 20.000-200.000mV
DCV: 2.000V - 1000.0V
ACV: 2.0000V - 750.0V
Curent:
ACD: 20.0A
ACA: 20.00A
Impedance: 200.00 - 100.00MΩ
Display: 8" color LCD, 800 x 600 pixels display，multi-touch screen
Input Impedance: 1MΩ ± 2%, in parallel with 15pF ± 5pF
Max Input Voltage: 1MΩ ≤ 300Vrms;
DC Gain Accuracy: ± 3%
Probe Attenuation Factor: 0.001X - 1000X, step by 1 - 2 - 5
Input Coupling: DC, AC, GND
Vertical Sensitivity: 1mV/div - 10V/div (at input)
Trigger Type: Edge, Video, Pulse, Slope, Runt, Windows, Timeout, Nth Edge, Logic, I2C, SPI, UART(RS232), and CAN (optional)
Bus Decoding(optional): I2C, SPI, UART(RS232), CAN
Trigger Mode: Auto, Normal, and Single
Automatic Measurement:
Vpp, Vavg, Vrms, Freq, Period, Week RMS, Cursor RMS, Vmax, Vmin, Vtop, Vbase, Vamp, Overshoot, Phase A→B ↑, Phase A→B↓, Preshoot, Rise Time, Fall Time,+Width, -Width, +Duty, -Duty, Duty Cycle, Delay A→B ↑, Delay A→B↓, +Pulse Count, -Pulse Count, Rise Edge Count, Fall Edges Count, Area, Cycle Area, FRR, FRF, FFR, FFF, LRR, LRF, LFR, LFF
Waveform Math: ＋, －, ×, ÷, FFT，FFTrms,Intg,Diff,Sqrt, User Defined Function, Digital Filter
Waveform Storage: 100 waveforms
Communication Interface: USB host, USB device,LAN, and WIFI (optional)
Frequency Counter: available
Battery: 7.4V, 8000mAh，5 hours operation
Dimension(WxHxD): 270x191x48
Device Weight: About 1.7kg
Accessories:
Power Cord, CD Rom, Quick Guide, Probe, Probe Adjust, Adapter, BNC-SAM, Micro USB Cable, Stand Holder
Optional: Soft Bag
