Bandwidth:200MHz
Sample Rate:1GS/s
Vertical Resolution (A/D)):14 bits
Record length:40M
Waveform Refresh Rate:70,000 wfms/s
Horizontal Scale (s/div)):1ns/div - 1000s/div, step by 1 - 2 - 5
Channel:4
Display:8" color LCD, 800 x 600 pixels display
Sample Rate / Relay Time Accuracy:±2.5 ppm
Input Coupling:DC, AC, GND
Vertical Sensitivity:1mV/div - 10V/div (at input)
Trigger Type:Edge, Video, Pulse, Slope, Runt, Windows, Timeout, Nth Edge, Logic, I2C, SPI, RS232,
and CAN (optional)
Bus Decoding(optional):I2C, SPI, RS232, CAN
Trigger Mode:Auto, Normal, and Single
Vertical Range:±2V(1mV/div～50mV/div)；±20V(100mV/div～1V/div)；±200V(2V/div～10V/div)
Waveform Math:+, -, *, /, FFT, Intg, Diff, Sqrt, and user defined function
Communication Interface:USB host, USB device, USB port for PictBridge, Trig Out (P/F), LAN, and VGA (optional)
Frequency Counter:available
Power Supply:100V - 240V AC, 50/60Hz, CAT II
Fuse:2A, T class, 250V
Battery (optional):3.7V, 13200mA
Dimension (W x H x D):340mmx177mmx90mm
Optional Module: VGA. WIF, AWG, DMM, MTS
Accessories: Power Cord, CD Rom, Quick Guide, USB Cable, Probe Adjust, Probe, Soft Bag (optional), Q9 (optional), Multimeter Lead(optional), Battery (optional), Capacitance Ext Module (optional)
