- Rated Power (VA): 750
- Output Form: 1Ø/2Ø
- Output Voltage Max (l-n/l-l):
Direct: 135/270
Transformer (Ratio 1.5:1; Ratio 2.0:1; Ratio 2.5:1): 202/404; 270/540; 338/600
- Output Current (Arms):
Direct: 4/2
Transformer (Ratio 1.5:1; Ratio 2.0:1; Ratio 2.5:1): 4/2; 3/1.5; 2.4/1.2
- Frequency Range:
Direct: 20~5000
Transformer (Ratio 1.5:1; Ratio 2.0:1; Ratio 2.5:1): 45~5000; 45~5000; 45~5000
- Input Power: 1Ø 47-63Hz
- Unit Height (In/mm/U): 5.25/133/3U
- Unit Weight (Lbs/Kg): 97/44
- Output Frequency:
20~5,000 Hz Direct Coupled
45~5,000 Hz Transformer Coupled
- Line Regulation: 0.1% max for a ±10% line
- Load Regulation:
Direct Coupled Ranges:
0.25% 20 ~ 2,000 Hz.
0.50% 2,000 ~ 5,000 Hz.
- Output Distortion:
0.1% THDAVG 45 ~ 1,000 Hz
0.25% THDAVG 20 ~ 5,000 Hz
- Ripple and Noise: -72dB
- Response Time: 5 μsec typ
