- Rated Power (VA): 6000
- Coupling Mode: Direct
- Form: 1Ø/2Ø; 3Ø
- Output Voltage Max (1Ø/2Ø; 3Ø) (l-n/l-l): 132/264; 132/228
- Current (1Ø/2Ø; 3Ø) (Arms): 48/16; 16/Ø
- Frequency Range: 15~1200
- Input Power: 3Ø 47~63Hz
- Unit Height (In/mm/U): 8.75/222/5U
- Unit Weight (Lbs/Kg): 145 /66
- Output Frequency:
15~1200 Hz Direct Coupled
45~1,200 Hz Transformer Coupled
- Line Regulation: 0.1% max for a ±10% line change
- Load Regulation:
+ 3Ø direct coupled:
0.25% 15 to 400 Hz.,
0.50% 400 to 1,200 Hz.
- Output Distortion:
0.25% THDAVG 15~200 Hz
1.25% THDAVG 200~1200 Hz
- Ripple and Noise: -66dB
- Response Time: 60 μsec typical
