Size Range: 0.3 to 25 μm
Size Channels: Factory calibrated at 0.3, 0.5, 1.0, 2.5, 5.0, 10.0 μm
Counting Efficiency: 50% @ 0.3μm; 100% for particles > 0.45 μm per JIS
Flow Rate / Accuracy: 1.2 LPM / ±3%
Concentration Limits: 27,000,000 particles/ft3 @ 10% coincidence (per ISO 21501-4), No appreciable drift. 50,000,000 particles/ft3 @ 10% coincidence (as tested and validated1)
Aerosol Concentration Range: 0.01 to 20,000 μg/m3
Light Source: Long life laser diode
Zero Count: <1 count / 60 minutes (<1 particles / 6 ft3). No fault count subtraction. No appreciable drift.
Resolution: 0.00003 μg/m3
Calibration: NIST Traceable
Internal Vacuum Pump: Integrated pump
Filtered Exhaust: HEPA filtered exhaust
Airflow: Internally monitored
Number of Channels: Up to 30 channels
Alarm: Adjustable built-in alarm
Communication Modes: Modbus (RTU/ASCII) via 3.3v UART
Standards: ISO 21501-4 and JIS B9921
Instrument Calibration: Recommended minimum once a year
Dimensions (L x W x H): 3.41 x 4.89 x 1.57 in (8.7 x 12.4 x 4.0 cm) includes inlet
Weight: 13 oz (368 grams)
Optional Accessories: 9300P-OEM Starter kit, 9000 Series Breakout Board, Square Base with flanges
Data Storage: 65,000 sample records (rotating buffer) with environmental data
Sample Time: 1 second to 99 hours
Power: 7 - 15 Vdc (< 2 watts max)
Operating Conditions: 41º to 104ºF (5º to 40ºC) / 20% to 95% non-condensing RH
Storage Conditions: 32° to 122°F (0° - 50°C) / < 98% non-condensing RH
