Color: Red
Width: 8.2 mm
Height: 52 mm, 47 mm, 54.5 mm
Length: 42.5 mm
Compliance: C-UR-US, CSA, KEMA EUR
Unit Weight: 13.076 g
REACH - SVHC: Details
Current Rating: 41 A
Mounting Style: DIN Rail (NS 32, NS 35/7.5, NS 35/15)
Voltage Rating: 800 V
Wire Gauge Max: 8 AWG
Wire Gauge Min: 24 AWG
Wire Gauge Range: 24 AWG to 8 AWG
Connection Method: Screw
Flammability Rating: UL 94 V-0
Number of Positions: 1 Position
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 60 C
