Current range: 0.1A~10A; 10A~200A; 200A~2000A
Attenuation ratio: 100mV/A （10X）; 10mV/A （100X); 1mV/A （1000X）
Accuracy: ≤3%+10mV; ≤2%+5mV; ≤1%+1mV
Bandwidth: 10Hz~100kHz(-3dB)
Max. dV/dt: 10A/μs
Max. current: when ＞1kHz，1000A Continuous current;If ≥1200A(no longer than 20 minutes）
Load impedance: ≥1MΩ and ≤47pF
Rise/Fall time: ≤3.5us
Working voltage: 600V rms
Common mode voltage: 600V CAT III and interference level 2
Diameter of maxillary mouth: 53mm
Max. Conductor size: Cable: maximum diameter:Ф52mm； bus harness； The single river flow row is:5х5mm and the four busbars are 30х5mm
Working Temperature/Humidity: 0~50℃/20~75%RH
Size: 216х111х45mm
Weight: 500g
