- DC input voltage:DC13.4V
- AC voltage no load: AC223V(±3%)
- Output power continuous: 1kW(±3%)
- Surge rating: 2000w(±3%)
- Effi ciency et rated power: 87%(±3%)
- No load current: no fan: 1.42A
on fan: 1.63A
- Low battery shut down: 10.2V(± 0.5V)
- Low battery return on power: 11.3V (± 0.5V)
- High battery shut down: 17.2V (± 0.5V)
- High battery return on power: 15.2V (± 0.5V)
- Equency[50/60] selection: 50hz/60hz selection (±0.8hz)
- Regulation: 1200W/219Vac
- Over temperature protection:-25℃ ~ 74℃ (78℃ ± 5℃)
- Over temperature power on: 58℃ (±5℃)
- Output wave form:Digital pure sine wave
- Cooling fan [auto fan]: Fan on temperature 40℃ (±5℃)
- Insulation transformer: 2KV ~ 2.5KV (±0.5KV)
- Over load protection:
Input fuse: 30A (1EA)
40A (2EA)
Output sensor: Included
Output fuse or breaker: 6A(SS-001)
AC outlet: 1P outlet 15A
- Transfer switch[inside]:
DC input: 12V(10V~17V)
Load current: 0.03A(30mA) / 220Vac
Switching time: 16~18msec (program control)
- Dimensions [W×H×D(mm)]: 482 X 44 X 352
- Weight:5kg
