- DC input voltage:DC48V
- DC voltage standard: 53.6V
- AC voltage standard: AC223
- Output power continuous: 10000W
- Surge rating: 20kw
- Effi ciency et rated power: 91%
- No load current: no fan: 0.65A
on fan: 1.41A
- Low battery shut down: 40.2V
- Low battery return on power: 42.5V
- High battery shut down: 61.0V
- High battery return on power: 59.0V
- Equency[50/60] selection:60hz
- Regulation: 10000W/222Vac
- Over temperature protection:-25℃ ~ +74℃
- Over temperature power on: 58℃
- Output wave form: Pure sine wave
- Cooling fan [auto fan]: Fan on temperature 40℃
- Insulation transformer: 2KV ~ 2.5KV
- Over load protection:
Input senser: 100A
Input fuse: 40A(8EA)
Output sensor: 50A
Output circuit breaker: 50AH(DCP-PR)
16A*2(SS-001)
AC outlet/terminal: 2P Outlet 16A / 1P-20A(EU-US)
3P-60A Terminal
- FCC (EMC) / AC120V: FCC part 15 sub part B class A
- KC (EMC) / AC220V: MSP-REM-pnk-DK4810K
- Dimensions [W×H×D(mm)]: 225×158×750mm
- Weight: 17.5kg
