- DC input voltage:DC24V
- AC voltage no load: AC223V(±3%)
- Output power continuous: 1000W (±5%)
- Surge rating: 2000W (±10%)
- Effi ciency et rated power: 91%(±3%)
- No load current: no fan: 0.6A
on fan: 1.7A
- Low battery shut down: 20.1V(± 0.5V)
- Low battery return on power: 22.7V (± 0.5V)
- High battery shut down: 31.9V (± 0.5V)
- High battery return on power: 29.9V (± 0.5V)
- Equency[50/60] selection: 50hz/60hz selection (±0.8hz)
- Regulation: 1200W/220Vac
- Over temperature protection:-25℃ ~ 74℃ (78℃ ± 5℃)
- Over temperature power on: 58℃ (±5℃)
- Output wave form:Digital pure sine wave
- Cooling fan [auto fan]: Fan on temperature 40℃ (±5℃)
- Input fuse:30A(2EA)
- Output sensor: 20A CT(Ts-7W)
- Output circuit breaker: 6A(SS-001)
- Solar MPPT Charger:
Input: System(battery) voltage: 24V
Maximum input Voltage (solar input): 75V (±3%)
Normal input power: 864W (± 15W)
No load loss: 30mA
Charging: Maximum Charging current: 30A (±3A)
Charging System: Auto
Float Charging Voltage: 26.4V (25℃) (±3%)
Equalization Charging Voltage: 28.8V (25℃) (±3%)
Working temperature: -25℃ ~ 74℃ (78℃ ±5℃)
Dimensions [W×H×D(mm)]: 287x85x350 mm
Weight: 5.6Kg
