PRODIGIT 3315G-02 DC Electronic Load (20V / 2.4A max)

Current: 1.2A / 2.4A max (chế độ Turbo ON).

Voltage: 20V

Power: 24W, 48W max

Protections:

Over Power Protection(OPP): 105%

Over Current Protection(OCP): 105%

Over Voltage Protection(OVP): 105%

Over Temp Protection(OTP): YES

* Constant Current Mode:

Range:

+ 0 ~ 0.12A/0.002mA

+ 0 ~ 1.5A/0.02mA

Accuracy: ± 0.01%

* Constant Resistance Mode:

Range:

+ 16.667Ω ~ 1000KΩ/1uS

+ 0.1200Ω ~ 16.667Ω/0.2778mΩ

Accuracy: ± 0.2%

* Constant Voltage Mode:

Range:

+ 0 ~ 2V/0.034mV

+0 ~ 20V0.34mV

Accuracy: ± 0.05%

* Constant Power Mode:

Range:

+ 0 ~ 2.4W/0.04mW

+ 0 ~ 24W/0.4mW

Accuracy: ± 0.5%

* Constant Current + Constant Voltage Mode:

Range Voltage : 20V/0.034mV

Range Current: 1.2A/0.02mA

Accuracy: ± 1.0%

Constant Power + Constant Voltage Mode:

Range Voltage: 20V/0.034mV

Range Power: 24W/0.4mW

Accuracy: ± 1.0%

Mode Turbo ON: max current 2.4A

Interface (optional) : GPIB, RS232, USB, LAN

Dimension: 143 x 108 x 412 mm

Weight: appr 3.7Kg
