Power: 35KW
Current: 0~35A/0~350A
Voltage: 0~1000V
Min.Operation Voltage: 10V@350A
Protections:
Over Power Protection (OPP): 105%
Over Current Protection (OCP): 104%
Over Voltage Protection (OVP): 104%
Over Temp Protection (OTP): Yes
CC mode:
Range: 35A/350A
Resolution: 0.56mA/5.6mA
Accuracy: ±0.1%
CR mode:
Range: 3428.4~2.857Ω/2.857~0.0288Ω
Resolution: 5.84uS/0.048mΩ
Accuracy: ±0.2%
CV mode:
Range: 10~1000V
Resolution: 16mV
Accuracy: ±0.05%
CP mode:
Range: 3500W/35000W
Resolution: 56mW/560mW
Accuracy: ±0.5%
Measurement mode (Load):
Voltage: 0 ~ 100V/100~1000V, ±0.025%
Current : 0 ~ 35A/35~350A, ±0.1%
Power : 3500W/35000W, ±0.125%
Short circuit current: 350A
Dimension (HxWxD): 1353 x 647 x 766 mm
Weight: 390 kg
Input: 115/230Vac, 50/60Hz
Optional interface: GPIB, RS232, USB, LAN
