Power: 40KW
Current: 0 ~ 20A; 0 ~ 200A
Voltage: 0 ~ 1250V
Protections: Over Power Protection (OPP); Over Current Protection (OCP); Over Voltage Protection (OVP); Over Temp Protection (OTP)
Constant Current Mode Range: 20A; 200A
Constant Resistance Mode Range: 7500Ω~6.25Ω; 6.25Ω~0.315Ω
Constant Voltage Mode Range: 1250V
Constant Power Mode Range: 4000W; 40000W
Constant Voltage Mode + Constant Current Mode Range: 1250V; 200A
Constant Voltage Mode + Constant Power Mode Range: 1250V; 40000W
Dynamic Mode:
- Timing: 0.040~9.999 / 99.99 / 999.9 / 9999mS
- Current: 0~20A; 15~200A
Measurement
- Voltage Read Back Range (5 Digital): 0~125V; 125~1250V
- Current Read Back Range (5 Digital): 0~20A; 20~200A
- Power Read Back Range: 1000W; 40000W
Short Current: 200A
Power Consumption: 3700Wmax
Dimension (HxWxD): 1509x647x766mm
Weight: 430 kg
Temperature: 0~40℃
