Counts: 3 5/6 (5999)
DCV: 600mV/6V/60V/600V ±(0.5%+4d); 1000V±(1.0%+6d)
ACV: 6V/60V/600V±(0.8%+10d); 750V±(1.0%+10d); 40~1kHz True RMS
DCA: 600μΑ/6000μΑ/60mA/600mA ±(1.0%+10d); 6A/10A±(1.2%+10d)
ACA: 600μΑ/6000μΑ/60mA/600mA ±(1.5%+10d); 6A/10A±(2.0%+15d); 40-1kHz True RMS
Resistance (Ω): 600Ω ±(0.8%+5d); 6k/60k/600K/6M ±(0.8%+4d); 60ΜΩ ±(1.2%+10d)
Capacitance
60nF ±(5.0%+30d); 600nF/6µF/60μF ±(3.5%+8d); 600µF/6mF/60mF±(5.0%+10d); 99.9mF (reference)
Frequency: 10/100/1K/10K/100K/1M/30M Hz ±(0.5%+4d)
Temperature (°C/°F)
(-20-1000)°C: <400°C ±(1.0%+5): ≥400°C ±(1.5%+15)
(-4~1832)°F: <752°F ±(1.0%+5): ≥752°F ±(1.5%+15)
Transistor Test: yes
Diode Test: yes
Continuity Buzzer: yes
Automatic Power Off: yes (15 minutes without operation).
Battery Low Display: yes
NCV & Live Line Detecting: yes
Operating Environment: 0-40°C; humidity <80%RH
Storage Environment: -10-50°C; humidity <80%RH
Power: 1.5V AAAx4 (not included)
Accessories: Test lead, K-type thermocouple, hFE Test adapter, Manual, USB Cable(TYPE-C)
Dimension: 189*88*56mm
Weight: Approx. 380g (batteries not included)
