Gain: 3.9 dB, 4.2 dB, 4.5 dB, 5 dB, 5.1 dB
VSWR: 3:1
Style: I-Bar Flex
Width: 20 mm
Height: 0.95 mm
Length: 100 mm
Impedance: 50 Ohms
Cable Type: 1.13 mm Mini Coaxial Cable
Unit Weight: 3.524 g
Cable Length: 100 mm
Polarization: Linear
Power Rating: 1 W
Mounting Style: PCB Mount
Number of Bands: 5 Band
Center Frequency: 850 MHz, 900 MHz, 1.8 GHz, 1.9 GHz, 2.1 GHz
Mechanical Style: PCB Trace
Maximum Frequency: 2.1 GHz
Minimum Frequency: 850 MHz
Termination Style: Connector
Antenna Connector Type: IPEX MHF
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE), GSM, UMTS, DCS, PCS, WCDMA
