Gain: 4.6 dBi, 4.9 dBi, 6 dBi, 6.6 dBi
VSWR: 2:1
Style: Sharkfin
Width: 88.5 mm
Height: 92.6 mm
Length: 195.1 mm
IP Rating: IP67
Impedance: 50 Ohms
Cable Type: 5.2 M LMR195 x 2, 5.2 M RG174
Application: Telematics, Fleet Management, Trucking, Navigation, GIS, Public Safety, Search and Rescure, Metering, Utility Boxes
Unit Weight: 1.134 kg
Cable Length: 5181 mm
For Use With: Fleet Management, Metering, Utility Boxes, Navigation, GIS and Survey, Public Safety, Trucking, Vehicular Use Telematics
Polarization: RHCP, Vertical
Power Rating: 45 W
Mounting Style: Magnetic Mount
Electrical Type: Active
Number of Bands: 4 Band
Center Frequency: 802 MHz, 2205 MHz, 2450 MHz, 5412.5 MHz, 1561.098 MHz, 1575.42 MHz, 1602.56 MHz
Mechanical Style: Module
Maximum Frequency: 5.925 GHz
Minimum Frequency: 644 MHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM, U-NII
Antenna Connector Type: RP-SMA Male, SMA Male
Protocol - GPS, GLONASS: BEIDOU, GLONASS, GNSS, GPS
Protocol - WiFi - 802.11: 802.11, WiFi, WLAN
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE), DSRC
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
