Gain: - 0.5 dBi, 1 dBi, 0 dBi
Style: Stubby
Length: 50 mm
Diameter: 12 mm
IP Rating: IP65
Impedance: 50 Ohms
Application: Gateways, Set Top Boxes, M2M, IoT, Telemetry. High Speed Data
Unit Weight: 7.800 g
Polarization: Linear
Power Rating: 5 W
Mounting Style: Panel Mount
Electrical Type: Monopole
Number of Bands: 1 Band
Center Frequency: 698 MHz, 2.2 GHz, 3.6 GHz
Mechanical Style: Whip
Ground Plane Size: 40 mm x 120 mm
Maximum Frequency: 3.8 GHz
Minimum Frequency: 617 MHz
Termination Style: Connector
Antenna Connector Type: SMA Male
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 30 C
Protocol - Cellular, NBIoT, LTE: 4G/5G, Cellular (NBIoT, LTE), GSM, UMTS
