Gain: 1.8 dBi, 2.55 dBi
Style: Straight
Length: 76 mm
Diameter: 7.9 mm
IP Rating: IP65
Impedance: 50 Ohms
Application: Wireless Application, V2x Communication, Rugged Outdoor Systems, Marine, Mining, Utility, Oil/Gas Environments, Industrial Applications, Metering, Security, IoT Applications, Outdoor Networking, Data Transmission, Access Points
Power Rating: 1 W
Mounting Style: Panel Mount
Number of Bands: 2 Band
Center Frequency: 2.45 GHz, 5.5 GHz, 5.5 GHz, 6.5 GHz
Mechanical Style: Whip
Maximum Frequency: 5.925 GHz
Minimum Frequency: 2.4 GHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM, U-NII
Antenna Connector Type: RP-SMA Male
Protocol - WiFi - 802.11: 802.11, WiFi, WLAN
Maximum Operating Temperature: + 65 C
Minimum Operating Temperature: - 35 C
Protocol - Cellular, NBIoT, LTE: 5G NR, Cellular (NBIoT, LTE)
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
