Structure:
Model: High balance
Needle Pitch: 50mm
Auxiliary Gas: yes
Buffer Structure: yes
The Discharge Electrode Can Be Replaced: yes
Texture Of Material:
Electrode Needle Material: Standard tungsten (titanium and silicon can be selected)
Body Material: SUS304/ABS/PC/PBT/PU/AL
Performance Parameter:
Ion Balance: ≤±30V
Electrostatic Removal Speed: 0.1S
Ion Balance Control Mode: SIS control system
Input Voltage: 20～36VDC
Voltage Operating Mode: Pulse AC
Rated Power: 24W
Rated Current: 1A
Frequency Setting: 10、20、50、60、100Hz
Working Distance: 50-1000mm
Recommended Installation Distance: 300mm
Size Of Gas Pipe Connector: Φ8mm
Connect The Sensor: /
Working Pressure: 0.1Mpa-0.5Mpa
Control Display:
Ion Indication: yes
Status Indication: yes
Cleaning Reminder: yes
Abnormal Discharge Indication: yes
Ion Level Self Balance: yes
Frequency Regulation: yes
Adaptive Calibration: yes
Work Environment:
Operating Ambient Temperature: 0～50℃
Operating Ambient Humidity: 0~70% RH (no freezing, no condensation)
Safety Specification:
Ce Standard: CE
Application:
Application Area: Electronic industry, automobile industry, etc
Note: The Measurement Conditions For The Above Data Are: Temperature (23 ± 3) ℃; Humidity (50 ± 5)%, Test Voltage 1Kv-100V; Test Distance 50Mm; Test Instrument: 3M711
