Gain: 17.5 dB
Technology: GaAs
Unit Weight: 823.300 mg
Mounting Style: SMD/SMT
Test Frequency: 2 GHz to 18 GHz
Input Return Loss: 11 dB
NF - Noise Figure: 2.5 dB
Operating Frequency: 2 GHz to 20 GHz
Supply Voltage - Max: 9 V
Operating Supply Current: 100 mA
Operating Supply Voltage: 5 V
P1dB - Compression Point: 20 dBm
OIP3 - Third Order Intercept: 29 dBm
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 40 C
