Gain: 4.36 dBi
VSWR: 3.5
Style: I-Bar Flex
Width: 15.2 mm
Height: 0.13 mm
Length: 90.15 mm
Impedance: 50 Ohms
Cable Type: 193 mm RF1.13
Application: Cellular Radio, Wireless Applications
Mounting Style: Adhesive Mount
Number of Bands: 1 Band
Center Frequency: 700 MHz, 750 MHz, 800 MHz, 900 MHz, 1176 MHz, 1190 MHz, 1202 MHz, 1227 MHz, 1242 MHz, 1268 MHz, 1278 MHz, 1575 MHz, 1602 MHz, 1621 MHz, 1700 MHz, 1800 MHz, 1900 MHz, 2200 MHz, 2500 MHz, 3500 MHz, 4500 MHz, 5500 MHz
Mechanical Style: PCB Trace
Maximum Frequency: 6 GHz
Minimum Frequency: 600 MHz
Termination Style: Connector
Protocol - Sub GHz: UHF
Antenna Connector Type: IPEX MHF4
Protocol - GPS, GLONASS: BEIDOU, GLONASS, GNSS, GPS
Protocol - WiFi - 802.11: WiMAX
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 20 C
Protocol - Cellular, NBIoT, LTE: 2G/3G/4G/5G, Cellular (NBIoT, LTE), GSM, UMTS, DCS, PCS, GPRS, WCDMA
