Spectrometer Specifications
Luminance Minimum: 0.02 cd/m²
Spectroradiometer Absolute Accuracy: Color Coordinates (x,y) ± 0.0015 for CIE standard illuminant A
Short-term Repeatability: ± 0.1% (2 sigma)
Minimum Measurement Time: 200 ms
Measurement Spot Size: Corresponding to ~600 I61 imaging colorimeter sensor pixels (in diameter)
Communication Interface: Ethernet 100/1000
Power supply: Wide-range input 100 - 240 VAC 50/60 Hz
Dimensions (H x W x D): 144 mm x 341 mm x 359 mm
Weight: 9 kg
Imaging System Specifications
Sensor Pixel Resolution: 9568 x 6380
Sensor Megapixels: 61.0
Sensor Type: CMOS
System Dynamic Range (single exposure, per pixel): 76 dB (1 x 1 binning)
Luminance (Minimum)*: 0.0005 cd/m² Limit of Detection
0.0010 cd/m² @ SNR = 60
0.0015 cd/m² @ SNR = 100
Luminance (Maximum): 10¹⁰ cd/m² with optional ND filters
Field of View (Full Angle, H x V degrees): 50 mm 40° x 28°/ 100 mm macro 20° x 14°
Minimum Measurement Time***: 0.6 sec - photopic/ 1.8 sec - color
Communication Interface: 10 Gigabit Ethernet (10 GigE)
