Primary Application: Production, Display Testing, Pixel-level Measurement, Advanced Vision
Sensor Pixel Resolution: 9568 x 6380
Sensor Megapixels: 61.0
Sensor Type: CMOS
System Dynamic Range (single exposure, per pixel): 76 dB (1 x 1 binning)
Luminance (Minimum)*:
+ 0.0005 cd/m² Limit of Detection
+ 0.0010 cd/m² @ SNR = 60
+ 0.0015 cd/m² @ SNR = 100
Luminance (Maximum): 10¹⁰ cd/m² with optional ND filters
System Accuracy**: Illuminance ± 3%; Luminance (Y) ± 3%
Short-term Repeatability: Illuminance ± 0.02%; Luminance (Y) ± 0.02%
Lens Type: Electronically controlled focus and aperture
Focal Distances Available: 35, 50, 100, 200 mm
Field of View (Full Angle, H x V degrees): 35 mm 55° x 37°;50 mm 40° x 28°; 100 mm macro 20° x 14°; 200 mm 11° x 7°
Minimum Measurement Time***: 0.7 sec
Spatial Measurement Capabilities: Luminance, Radiance, Illuminance, Irradiance, Luminous Intensity, Radiant Intensity
Units: foot-lambert, cd/m2, nit, W/sr/m2, foot-candles, lux, lux-s, W/m2, W-s/m2, candela, W/sr
Communication Interface: 10 Gigabit Ethernet (10 GigE)
Power: External AC / DC adapter, 100-240 V, 50-60 Hz, 60 Watts
Dimensions (H x W x D): 86 mm x 86 mm x 170 mm
Weight: 1.2 kg
Operating Temperature: 5-35° C
Operating Humidity: 20 - 70% non-condensing
