Detector Type: Uncooled infrared detector
Infrared Resolution: 640×512
Pixel Size: 12μm
Spectral Band: 7.5-14μm
Thermal Sensitivity (NETD): ＜25mK (25°C,F1.0)
Frame Rate: 25Hz
Lens Focal Length: Standard lens: 17.7mm; super telephoto lens: 60.9mm; telephoto lens: 31.5mm; wide-angle lens: 9.5mm; macro lens (0.2×): 13mm; super macro lens (0.4×): 14.8mm.
FOV: Standard lens: 25°×20°; super telephoto lens: 7°×5.6°; telephoto lens: 14°×11.2°; wide-angle lens: 45°×36°.
Spatial Resolution (IFOV): Standard lens: 0.68mrad; super telephoto lens: 0.2mrad; telephoto lens: 0.38mrad; wide-angle lens: 1.26mrad; Macro lens: One pixel corresponds to 60μm; super macro lens: One pixel corresponds to 30μm.
Focusing Mode: Electric micro focus, manual focusing, one-button center focus, automatic center focus, single-touch automatic focusing, laser-assisted focus
Measurement Range: -20°C~+150°C, 100°C~650°C; optional: 400°C~+1500°C
Measurement Accuracy: ±2°C or ±2% of readings, whichever is greater
Imaging Display
Display: 5.5-inch LCD touch screen, resolution 1920×1080
Visible light camera: 13 megapixels
Digital Zoom: 1× ~ 10 ×
Palettes: 19 options
Image Mode: Infrared, visible light, PIP, dual-spectrum fusion
Temperature Width Stretch: support
Measurement and Analysis
Analysis Functions on the Device: Support up to 25 movable points, lines, frames, circles and polygons, and up to 5 preset modes
Supporting Software: PC (Infrared Analysis Software) & Mobile Device (iOS/Android APP)
Laser Rangefinding: Support
Area Measurement: Support
Hygrothermograph: Support
Position: Support
Temperature Difference Analysis: Support
Trend Analysis: Supports temperature trend recording and analysis.
Image Freezing: Support
Analysis Report: PDF format. Support editing and template importing on the PC client.
Image Storage
Standard 64GB MicroSD. Support SD, SDHC, and SDXC, up to 2TB.
Text Notes: support
Voice Annotation: support
Video Functions
Radiation Infrared Video Recording: Support compressed full radiation video recording (.irv), up to 15Hz video recording
Non-radiation Infrared or Visible Light Video Recording: Standard MP4 video recording
System Functions
Intelligent Routine Inspection: Support. General task package import and editing, standard and automatic naming of images
Communication Protocol: Wi-Fi, Bluetooth, USB
Others
Battery: 9000mAh lithium-ion battery, field-replaceable, fast charging
Charging Mode: USB Type-C or desktop charger
Battery Life: Continuous operating time ≥ 3 hours (depending on the actual environment and service conditions)
Interface: USB3.0 Type-C, SD card, SIM card, Mini HDMI
Tripod Socket: UNC 1/4-20 interface for tripod
Operating Temperature: -15°C~+50°C
Operating Humidity: 10%~95% (non-condensing)
Storage Temperature: -40°C~+70°C
Ingress Protection Rating: IP54
Shock and Vibration
Shock: 25g (IEC 60068-2-27); vibration: 2.5g (IEC60068-2-6)
Weight and Dimensions: About 1.3kg (with battery), 278×116×113mm
Packing List: Thermal camera, manual, quick operation guide, data download card, , multi-country adapter,, USB data cable, lithium-ion battery×3, portable bag, charging cradle, HDMI cable, hand strap, backpack strap, SD card, charging stand, standard lens.
