Basic Features
Laser Wavelength: 905±5 nm
Eye-safe Level: Class 1 (IEC 60825-1)
Laser Divergence Angle: ~1×6mrad
Rangefinding Performance (for buildings): 5~600m
Measuring Accuracy: ±1m
Measuring Frequency: 5~45m, 3Hz; >45m, 0.75~3Hz
Emitting Aperture: Φ10×7.5mm
Receiver Aperture: Φ15×10mm
Detection Probability: ≥98%
False Alarm Rate: ≤1%
Electrical Characteristics
Communication Interface: UART (TTL_3.3V)
Baud Rate: 9,600/14,400/19,200/38,400/57,600/115,200 (default)/128,000/230,400
Power Supply Mode: DC3-5V
Maximum Power Consumption: 0.3W
Standby Power Consumption: ≤1mw (Power ON < 0.3V)
Physical Characteristics
Weight: 10±0.5g
Dimensions: <25×26×13mm
Shock Resistance: 1,200g, 1ms
Vibration Level: 5~50~5Hz, 1 octave/min, 2.5g
Environment Adaptability
Operating Temperature: -40℃~+60℃
Storage Temperature: -40℃-+60℃
