Performance Indicators
Detector Type: Uncooled VOx infrared detector
Resolution: 640×512
Detector Frame Rate: 50Hz
Pixel Pitch: 12μm
Spectral Band: 8~14μm
NETD: ≤50mK at 25°C (≤40mK, optional)
Image Adjustment
Brightness/Contrast Adjustment: Manual/Automatic/Linear
Polarity: Black-hot/White-hot
Palette: support
Reticle: Display/Blank/Move
Image Processing: Scene-based non-uniformity correction, digital filtering noise reduction, and digital detail enhancement, Shutterless supported.
Mirroring: Horizontal/Vertical/Diagonal
Power Supply
Power Supply Range (typical): 3.8～5.2VDC / 1.8V / 3.3V
Typical Power Consumption at 25°C Without Extension: 0.35W
Interface
Digital Video: CDS2/CDS3/LVCMOS/MIPI
Serial Communication Interface: UART/I2C (optional)
Extension Components: USB2.0 / Analog video
Temperature Measurement Performance
Measurement Range: For measurement series, -20°C~+150°C, 0℃~+650°C
Measurement Accuracy: For temperature measurement series, ±3°C or ±3% at ambient temperature of -20°C~+60°C (±2°C optional)
Measurement Tool: Secondary analysis of points, lines, and areas
Physical Characteristics
Dimensions (Without lens and extension components): 21×21mm
Weight (3.2mm, without extension components): 8g
Lens Model: 4.1mm, 6.9mm, 9.1mm, 13mm, 25mm, and 45mm
Environment Adaptability
Operating Temperature: -40°C~+80°C (-20°C~60°C measurement)
Storage Temperature: -45℃～+85℃
Humidity: 5 ~ 95%, non-condensing
