Width: 8 mm (0.315 in)
Height: 12.2 mm (0.48 in)
Length: 23 mm (0.906 in)
Industry: Medical
Compliance: ANSI; CB; CSA; IEC; REACH; RoHS; UL
Efficiency: 77%
Unit Weight: 4.400 g
Output Power: 2 W
Input Voltage: 2.97 V to 3.63 V
Mounting Style: Through Hole
Isolation Voltage: 5.2 kV
Number of Outputs: 1 Output
Input Voltage - Max: 3.63 V
Input Voltage - Min: 2.97 V
Input Voltage, Nominal: 3.3 V
Output Current-Channel 1: 606 mA
Output Voltage-Channel 1: 3.3 V
Maximum Operating Temperature: + 95 C
Minimum Operating Temperature: - 40 C
