Width: 7.05 mm (0.278 in)
Height: 10.2 mm (0.402 in)
Length: 19.65 mm (0.774 in)
Industry: Industrial
Compliance: IEC; REACH; RoHS
Efficiency: 85%
Unit Weight: 2.800 g
Output Power: 2 W
Input Voltage: 10.8 V to 13.2 V
Mounting Style: Through Hole
Isolation Voltage: 3 kV
Number of Outputs: 1 Output
Input Voltage - Max: 13.2 V
Input Voltage - Min: 10.8 V
Input Voltage, Nominal: 12 V
Output Current-Channel 1: 222 mA
Output Voltage-Channel 1: 9 V
Maximum Operating Temperature: + 80 C
Minimum Operating Temperature: - 40 C
