Width: 25.4 mm (1 in)
Height: 10.2 mm (0.402 in)
Length: 50.8 mm (2 in)
Industry: Industrial
Compliance: EAC; REACH; RoHS; UL
Efficiency: 84%
Unit Weight: 27 g
Output Power: 10 W
Input Voltage: 9 V to 18 V
Mounting Style: Through Hole
Isolation Voltage: 1.6 kV
Number of Outputs: 2 Output
Input Voltage - Max: 18 V
Input Voltage - Min: 9 V
Input Voltage, Nominal: 12 V
Standard Packaging Size: 2 x 1
Output Current-Channel 1: 1 A
Output Current-Channel 2: 1 A
Output Voltage-Channel 1: 5 V
Output Voltage-Channel 2: - 5 V
Maximum Operating Temperature: + 100 C
Minimum Operating Temperature: - 25 C
