Width: 25.4 mm (1 in)
Height: 16.5 mm (0.65 in)
Length: 31.4 mm (1.236 in)
Industry: Industrial
Compliance: EAC; REACH; RoHS; UL
Efficiency: 85%
Unit Weight: 21.440 g
Output Power: 15 W
Input Voltage: 9 V to 18 V
Mounting Style: Through Hole
Isolation Voltage: 1.6 kV
Number of Outputs: 2 Output
Input Voltage - Max: 18 V
Input Voltage - Min: 9 V
Input Voltage, Nominal: 12 V
Standard Packaging Size: 1 x 1
Output Current-Channel 1: 1.5 A
Output Current-Channel 2: 1.5 A
Output Voltage-Channel 1: 5 V
Output Voltage-Channel 2: - 5 V
Maximum Operating Temperature: + 68 C
Minimum Operating Temperature: - 40 C
