Width: 9.2 mm (0.362 in)
Height: 11.1 mm (0.437 in)
Length: 21.8 mm (0.858 in)
Industry: Industrial
Dimensions: 21.8 mm x 9.2 mm x 11.1 mm
Application: Railway, Telecom
Output Power: 2 W
Input Voltage: 4.5 VDC to 36 VDC
Mounting Style: Through Hole
Isolation Voltage: 3 kV
Number of Outputs: 1 Output
Input Voltage - Max: 36 V
Input Voltage - Min: 4.5 V
Input Voltage, Nominal: 24 V
Output Current-Channel 1: 167 mA
Output Voltage-Channel 1: 3.3 V to 17 V
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
