REN THANG RF-101-MB Powerful Axial Lead Forming Machine

Body length: 3.8 - 20 mm

Body diameter: 2.3-8 mm

Shoulder: 1.2 min

Height: Fixed at 8mm or more

Lead Length: Adjustable

Support point: 2 ~ 3mm

Pitch: A + 2C

Wire diameter: 0.4-1.3 mm

Power: 110V/60Hz ; 220V/50Hz

Dimension: 1050(L), 600(W), 650(H) mm

Weight: (N.W.) 115 Kgs. (G.W. ) 150 Kgs

Moving control: Manual rotation, stepping intermittent, Fully automatic, three different modes for choice.

FEATURES:

MB type, targets for TAPED parts fed by guides.

RF-101MB, forms and kinks leads into U shape with kinks on leads.

Tailor-made die set is available for most forming specification. Welcome to email the spec. drawing for our best solution for you.

Kink /MK type forming machine is suitable for the massive production line.

Ready-to-use setup: customers can use the machine right after receiving it.

OEM, DIP, PCBA Insertion line's most helpful equipment!

Rarely damage component leads or components body. (If it happens, please feel freel to consult us. )
