Voltage (Module): 60V–300V
Voltage (PACK): 60V–2000V
Charge and Discharge Current: 0–800A
AC Withstand Voltage: 0.05–5KV
DC Withstand Voltage: 0.05–6KV / 7.2KV / 10KV
AC Impedance: 0.1mΩ–3KΩ
DC Impedance: 0.1mΩ–3Ω
Insulation Resistance: 0.01MΩ–9.99GΩ / 50GΩ / 99.9GΩ
Ground Resistance: 0.001Ω–1.200Ω
Open-circuit Voltage: 0–1500V
BMS Communication Module: Supports communication protocols such as CANBus and RS485
Special Custom Module: Signal generator, air tightness detector, etc
Cabinet Size (WDH mm): 640 * 850 * 1980
ADVANTAGES
Integrated high-precision meter, reliable and standard testing result
Support production verification and research-oriented test for R&D
High compatibility, satisfy different testing requirements on module, mono box, and PACK unit
Functional module is expandable as required
Intelligent and automatic work process to save labors and improve testing efficiency
Exclusive open software platform, support instruments and meters of other brands
Software supports the analysis of various BMS communication protocols, pass-through analyze, without any algorithm process
Testing function and project development can be customized as required
APPLICATIONS
Applied in e-vehicle, e-bus, energy storage base, PACK EOL testing, and quality control
