Measuring Range (in kN): 45 kN
Measuring Range (in lbf): 10000 lbf
Measuring Range (in kgf): 4500 kgf
Accuracy: ± 3 % full scale
Measuring unit: N, lbf, kgf switchable
Material diameter: 4.75 – 25.4 mm (3/16 – 1 inch)
Loading Error: Rope elongation of only 2 mm
Display information: Unit, wire, shaver and battery status
Display: LCD 2.54 cm high, full text prompts
Number of calibrations: Up to 20 calibrations can be saved
Resolution:
+ CTM-10000: low (200 N/50 lbf/20 kgf), middle (100 N/20 lbf/10 kgf), high (50 N/10 lbf/5 kgf)
Output Signal: RS-232
Power supply: 2 batteries, size AA (approx. 120 h of use)
Temperature range: -20 up to +70 °C
Dimensions: 59x 25x 8 cm
Weight, net (gross): Approx. 5 kg (11 kg)
Delivery Includes: carrying case including calibration for one material, roller set (as requested), operating instructions in English
