Tension Ranges: 5 – 20 daN
Measuring Head Width*: 216 mm
SCHMIDT Calibration Material**: PA: 1.50 mm Ø
Material Thickness Compensator: yes
Calibration: According to SCHMIDT factory procedure
Accuracy: ±1 % full scale or ±1 graduation on scale
Scale diameter: 41 mm
Temperature range: 10 – 45 ºC
Air humidity: 85 % RH, max.
Housing material: Die-cast aluminium
Dimensions: See dimensions
Weight, net (gross): Up to DX2-10K approx. 470 g (1000 g); DX2-20K-L approx. 580 g (2000 g)
Other tension ranges and measuring head widths available on request.
Other units of measure available – g or kg.
* Depending on model, either width of filament guide or outer distance between outside guide rollers
** Suitable for 95 % of applications – PA = Polyamide Monofilament
Delivery Includes: carrying case, operating instruction in German or English (as requested), Certificate of compliance with the order 2.1 according EN 10204 free of charge
