Nominal Conversion Loss (in 50 Ω System): 33.9 dB
Transfer Impedance: 1 Ω
Frequency Range: 10 kHz – 200 MHz
Conversion (Current → Voltage): 1 µA = 1 µV
Usable Frequency Range with AC < 0.6 A (50 Hz): 10 kHz – 200 MHz
Usable Frequency Range with AC < 2 A (50 Hz): 50 kHz – 200 MHz
Usable Frequency Range with AC < 4 A (50 Hz): 100 kHz – 200 MHz
Usable Frequency Range with AC < 10 A (50 Hz): 1 MHz – 200 MHz
Connector: BNC female
Dimensions: 36 × 119 × 10 (25) mm
Maximum Wire Diameter: 6.5 mm
Weight: 110 g
