Applicable range of cutting part: 0.01 ~ 400 mm² (φ0.01 – 30 mm)
Cutting speed: 1–2800RPM
Grinding speed: 1–2800RPM
Cutting wheel: Outer Diameter 150MM, ID: 32MM, Thickness: 0.5MM
Z axis fine-tuning range: 0.00MM – 10.00MM
Cooling system: Automatic water circulation system (effectively reducing the impact of high temperature on the internal structure during the cutting process)
Image capture part: Imported 5 million digital high-quality, low-distortion optical instruments
Magnification: 0.7X, 1X, 1.5X, 2.0X, 2.5X, 3.0X, 3.5X, 4.0X, 4.5X (0.5 card position shift technology)
Video magnification: 16X – 500X
OD of specially made sandpaper: 150MM (1000#, 2000#)
Fixture part: Using high-end three-axis clamps, irregular wire harness terminals can also be clamped
Electrolysis time: 5–30 Seconds
Dimensions: 1700 × 800 × 850MM
Weight: About 200KG
