Dimension: 194 (H) X 152.4 (W) X 136 (D) mm
Weight: 4kg
Operating Voltage : DC : 24V ±10%; PoE : 36V~57V (Typical : 48V)
Flow Rate : 100~1000ml (Normal 300~500ml/min)
Power Consumption : Approximately 5.0W
Measuring Type Display : FND, Gas concentration, Flow rate, Alarm, Device faulty
Relay : Low Alarm, High Alarm, Fault Alarm
Output Signal : 4-20mA
Digital Communication : RS-485, TCP Ethernet
Sampling Distance : Length of input gas tube : Up to 30m (FEP tube); Length of exhaust gas tube : Up to 30m (FEP tube)
Input/Output Tube : 1/4” Teflon tube
Operating Temperature: -40°C ~ +55°C
Control/Set : 4 Buttons & RS-485 & Ethernet & Bluetooth
Remote Interface : Ethernet, RS-485
Wiring : 4 to 20mA / DC power / Relay : Up to 14 AWG
Pressure range : 90 to 100kPa
Maximum Sample flow : Max 1000ml
Maximum Sample Pressure: 6kPa
Certification: IECEx: Ex db llC T6 Gb; ATEX: II 2 G Ex db IIC T6 Gb
