Test voltage (DC V) and Measuring ranges:
50V / 0.1MΩ~400MΩ ;100V / 0.1MΩ~800MΩ
125V / 0.1MΩ~1GΩ ;250V / 0.2M~2GΩ
500V / 0.2MΩ~4GΩ; 1000V / 0.2M~8GΩ
Output voltage @ 1mA Rated test Voltage +10% Max
Accuracy :0.2M~4GΩ : ±3%rdg ,4GΩ~8GΩ : ±5%rdg
Continuity
Measuring range:0.01-1999Ω
Accuracy:0.01-100Ω : ±1.0%rdg, 100-300Ω : ±1.5%rdg, 300-1999Ω : ±2.0%rdg
Resolution : ±2 counts
Voltmeter
AC voltage (Auto): 0-700V
DC voltage (Auto):0-950V
Accuracy : ±1.5% rdg
Resolution : ±1V
MOV Test & GAS Arrester Test
Measuring range 5~1020 Vdc
Accuracy ±(3%rdg + 2dgt)
Protections
Over load :700V
(between all terminals)
Load battery test current: About 300mA
Dimensions: 250(L) × 190(W) × 110(D)mm
Weight
(battery included): Approx. 1460g
Power source: 1.5V (AA) × 8
Safety standard : EN 61010-1 CAT III 600V
EN 61326-1 Accessories : Instruction manual, Test leads, Shoulder belt, Batteries
