CWDM Module:
Wavelength (nm):1271~ 1611
Channel Number: 18
Power Range (dBm): -50 ~ +10
Channel Spacing: 20nm
Central Wavelength: ITU
Channel Band-pass: ITU±6.5nm
Channel Power Resolution: ±0.01 dB
Channel Power Accuracy: ±0.5 dB
Channel Power Repeatability: ±0.5 dB
Maximum Input Power: 13 dBm
ORL: >45 dB
Measurement Unit: W/mW/μW/nW/pW/dBm/dB (REF)
Data Storage: 1000 sets
Connectivity: USB
Detector Type: InGaAs
Application Range: Singlemode Fiber
Connector: FC/PC (Interchangeable SC/ST)
Power Saving: Auto-off after 5 minute idle
OPM Module:
Calibrated Wavelength (nm): 850, 1300,1310,1490,1550,1625
Power Range (dBm)(1): -70 ~ +10
Accuracy: ± 5% ± 0.01nW(±0.5 dB@850nm)
Resolution: 0.01 dB
General Specifications:
Power Supply: NiMH Rechargeable Battery / AC Power Adaptor
Battery Life: Continuous operation ≥10 hours
Weight: 1kg (2.2 lbs)
Dimensions (H × W × T): 220×110×70mm (8.7×4.3×2.7 inch)
Note: (1) At 850nm, the lower limit of measurement range is -60 dBm:
* Specifications subject to change without notice:
Ordering Information:
Standard Package::
Instrument, NiMH battery, AC adaptor, USB data cable, OCC software CD, Soft carrying case, Warranty card, Certificate of calibration, User’s guide.:
