Direct access to our certified experts
Configuration control
via dataset: Yes
Control elements
Mode selector switch: 1
Supply voltage
Rated value (DC): 24 V
permissible range, lower limit (DC): 19.2 V
permissible range, upper limit (DC): 28.8 V
Reverse polarity protection: Yes
Mains buffering
Mains/voltage failure stored energy time: 10 ms
Input current
Current consumption (rated value): 0.51 A
Current consumption, max.: 0.7 A
Inrush current, max.: 1.34 A; Rated value
I²t: 0.3 A²·s
Power
Infeed power to the backplane bus: 8.05 W
Power loss
Power loss, typ.: 3.5 W
Memory
Number of slots for SIMATIC memory card: 1
SIMATIC memory card required: Yes
Work memory
integrated (for program): 200 kbyte
integrated (for data): 1 Mbyte
Load memory
Plug-in (SIMATIC Memory Card), max.: 32 Gbyte
CPU processing times
for bit operations, typ.: 25 ns
for word operations, typ.: 32 ns
for fixed point arithmetic, typ.: 42 ns
for floating point arithmetic, typ.: 170 ns
