Workpiece
Max. Mass: 10.0kg
Span across Bearings: 160mm max.
Max. rotor length: 390mm
Mechanical unit
Belt drive system: Upward-Tangential
Motor: AC servo motor, 400W
Balancing speed: 200 to 4,500min^-1 (Depending on outer diameter of workpiece)
Bearing support system: Soft type
Angle of unbalance index: Automatic indexing
Between bearings method: V block bearing
Safety cover: Sliding door with LS -optional
Vibration sensor: Optical touchless displacement sensor
Rotation sensor: Fiber sensor
Measuring unit
Min. Achievable Unbalance: 0.1 µm
Balancing plane: 1 and 2
Balancing method: Multi-speed multi-plane, Fix-speed multi-plane
Angle of unbalance index: Automatic indexing
Graphic display: 5.7" TFT color LCD with touch screen
Min. unbalance indication: 0.01mg
Indication mode: Polar coordinates and (3 to 24) components of unbalance vector (add or remove of unbalance correction masses are selectable)
No. of stored work data: 30 data
Judgment of measured result: Judgment with set limit value
Data transfer: Measured data can be transferred to PC
Others
Power supply: 3-phase AC200V 50/60Hz
Dimensions: 810(W) × 625(L) × 1,200(H)mm
Mass: Approx. 200kg
