Thermoelemente (TC):
Generation and measurement of TC signals : J, K, T, R, S, B, N, E
mV-generator function : -10...1100 mV
mV-measurement function: -10...110 mV
Accuracy (of reading + const.) : ±0.05 %
Selectable temperature unit : °C / °F
Internal comparison point : ±0.5 °C
Generation:
High-speed call values : -
Linear steps and ramps: -
User-defined synthesiser values : -
User-defined signal output characteristic : -
Editable units : -
Measurement:
Data memory : -
Value tables and graphics function : -
Offset programming for sensor characteristic: -
Calibration data files and linearisation points: -
User-defined measuring input characteristic : -
Editable units : -
Measured value min. / max. : -
Measured value hold function : -
Averaging function : -
Features:
Sensor connection : 4 safety sockets (1 channel) incl. 2 sets with safety instrument leads (4 mm) and alligator clips
Power supply : 1 x 9 V monobloc battery; Operating time approx. 25 h with auto-power-off
PC Interface : -
Operator guidance: Keypad
Display : Multifunction display LCD, 5½ digit
Housing:
Version : ABS plastic with protective cover
Dimensions : 200 x 100 x 40 mm (H x W x D)
Weight : Approx. 550 g
