Current (mA):
Loop current signal generation : 0(4)...25 mA
Loop current signal measurement : -6...25 mA
Accuracy (of reading + const.) : ±0.015 %
Current loop supply : 24 V ±10 %, 25 mA
HART Communication protective resistor : 250 Ω
Voltage (V):
Voltage signal generation : 0...10(15) V
Voltage signal measurement : -5...50 V
Accuracy (of reading + const.) : ±0.015 %
Continuity (O/C):
Continuity measurement : O / C
Switching threshold „open“: 1 kΩ
Generation:
High-speed call values : 10 points (flexible)
Linear steps and ramps : ✓
User-defined signal output characteristic: 10 points
Editable units: ✓
Measurement:
User-defined measuring input characteristic : 10 points
Editable units : ✓
Measured value min. / max. : ✓
Measured value hold function : ✓
Averaging function : ✓
Features:
Sensor connection :
Power supply : 4 x 1.5 V AA-battery; Operating time approx. 25 h or rechargeable battery including power adapter 230 VAC / 12 VDC (optional)
PC Interface : mini-USB Type B
Operator guidance : Menu with pull-down windows
Display : Multifunction display LCD, 6 digit
Housing:
Version : ABS plastic with protective cover
Dimensions : 160 x 85 x 45 mm (H x W x D)
Weight : Approx. 300 g
