Frequency: 50Hz / 60Hz
Primary Current (A): 0.6, 1, 1.5, 2.5, 3, 4, 5, 6, 7.5, 8, 10, 15, 20, 30, 50, 60
Secondary Current (mA): 1, 1.5, 2, 2.5, 3, 10/3, 4, 5, 20/3, 7.5, 8, 10, 15, 50/3, 20, 25, 30, 100/3, 50
Rated Current Ratio: Arbitrary combination of Primary Current and Secondary Current
Accuracy Class: 0.02%
Operation Range: (5% - 300%).In
Secondary Burden: 10Ω
Power Factor: COSΦ = 1.0
Voltage Level: AC 600V
Insulation: Air
Operating Condition: Temperature: -5℃ ～ +40℃, Relative Humidity (RH): up to 85% (max 90%)
Dimension (mm): 460 x 380 x 160
Weight (kg): ~15kg
