Gain: 0.5 dBi, 1 dBi, 2 dBi
VSWR: 3:1
Style: T-Bar
Width: 29.25 mm
Height: 4.2 mm
Length: 154.25 mm
Frequency: 824 MHz to 960 MHz, 1.71 GHz to 2.17 GHz, 2.3 GHz to 2.7 GHz
Impedance: 50 Ohms
Cable Type: 2.5 RG174
Application: Cellular Applications, Wireless Applications
Unit Weight: 40 g
Cable Length: 2.5 m
Polarization: Vertical
Power Rating: 1 W
REACH - SVHC: Details
Mounting Style: Adhesive Mount
Electrical Type: Dipole
Frequency Range: 824 MHz to 2.7 GHz
Number of Bands: 3 Band
Center Frequency: 868 MHz, 915 MHz, 1800 MHz, 1900 MHz, 2100 MHz, 2500 MHz
Mechanical Style: Module
Maximum Frequency: 2.7 GHz
Minimum Frequency: 824 MHz
Termination Style: Connector
Antenna Connector Type: SMA Male
Protocol - WiFi - 802.11: WiFi
Maximum Operating Temperature: + 60 C
Minimum Operating Temperature: - 30 C
Protocol - Cellular, NBIoT, LTE: 2G/3G/4G, Cellular (NBIoT, LTE), GSM, UMTS, DCS, PCS, GPRS, WCDMA
