Gain: 5 dBi
VSWR: 2
Style: Straight with Base
Length: 311 mm
Diameter: 40 mm
Frequency: 824 MHz to 960 MHz, 1.71 GHz to 2.17 GHz
Impedance: 50 Ohms
Cable Type: 3 M RG174
Application: Cellular Applications, ISM Applications
Unit Weight: 70 g
Cable Length: 3 m
Polarization: Linear
REACH - SVHC: Details
Mounting Style: Magnetic Mount
Frequency Range: 824 MHz to 2.17 GHz
Number of Bands: 4 Band
Center Frequency: 868 MHz, 915 MHz, 1.8 GHz, 1.9 GHz, 2.1 GHz
Mechanical Style: Whip
Maximum Frequency: 2.17 GHz
Minimum Frequency: 824 MHz
Termination Style: Connector
Protocol - Sub GHz: ISM, RFID
Antenna Connector Type: SMA Male
Protocol - WiFi - 802.11: WLAN
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 45 C
Protocol - Cellular, NBIoT, LTE: 2G/3G, Cellular (NBIoT, LTE), GSM, UMTS, DCS, GRPS, PCS
