Width: 127 mm (5 in)
Height: 41 mm (1.614 in)
Length: 249 mm (9.803 in)
Industry: Industrial
Approvals: EN60950-1, UL60950-1
Compliance: EN60950-1, UL60950-1
Efficiency: 89 %
Output Power: 800 W
Input Voltage: 100 VAC to 240 VAC
Mounting Style: Chassis
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 3 kVrms
Number of Outputs: 1 Output
Open Frame/Enclosed: Enclosed
Output Current-Channel 1: 66.7 A
Output Voltage-Channel 1: 12 VDC
Operating Temperature Range: - 25 C to + 60 C
Maximum Operating Temperature: + 60 C
Minimum Operating Temperature: - 25 C
